titanium plate for heat exchanger

Titanium Plates, coil, Sheet, and Foil
We provide high quality titanium plates, titanium sheet, and titanium foil directly from China according to customer's requirements. Sheets and plates made of molybdenum and nickel are also available.
Quantity:
  • P010

  • elegant

Titanium Plates, coil, Sheet, and Foil
We provide high quality titanium plates, titanium sheet, and titanium foil directly from China according to customer's requirements. Sheets and plates made of molybdenum and nickel are also available.
Hot rolling titanium plates/ coils are good material for further processing such as petroleum, chemical, electric power, medicine and environmental protection, and other various fields. Complete in specifications, variety of products, breadth, long Ti-coils, good strip shape, high precision of specification, stable in performance, punctual delivery, four forms: Ti-plates, Ti- coils, Ti-sheets, Ti-foils. We have many different kinds of delivery status such as hot rolling, annealing, shot blasting, acid picking.
Cold rolling titanium plates/ coils are widely used in petroleum, chemical, electric power, medicine and environmental protection, and other various fields. Complete in specifications, variety of products breath, good in shape, high precision of specification, surface cleanliness and consistency, homogeneous in organization.
Grades:
﹒ASTM GR.5, ASTM GR.7, ASTM GR.9, ASTM F136, TC4, TA8, TA9, Ti 15-3-3-3
﹒TA-0, TA1-A, TA1, TA2, ASTM GR.1, ASTM GR.2, ASTM ERT-1, ASTM ERT-2, ASTM F6

Titanium Plates
Manufactured according to ASTM B265. Custom cuttings on demand.

Materials Manufacturing Process Processing State Standards
TA1, 2, 9, 10,
Gr1, 2, 3, 7, 11, 12, 17
Hot rolled
 (3.0mm < T < 60mm)
Hot rolled,
annealed

Shot blasting
Acid picking
ASTM B265-95
 GB/T3261-2007
TA1, 2, 9, 10,
Gr1, 2, 3, 7, 11, 12, 17
Cold rolled
 (0.2mm < T < 4.0mm)
Cold rolled,
 annealed

smooth
ASTM B265-95
GB/T3261-2007
TC1, TC2, TC4
Gr5, Gr23
Hot rolled
(4.1mm < T< 60mm)
Hot rolled,
annealed

Shot blasting
Acid picking
ASTM B265-95
GB/T3261-2007
TC1, TC2, TC4
Gr5, Gr23
Cold rolled
 (0.2mm < T < 4.0mm)
Cold rolled,
annealed

smooth
ASTM B265-95
GB/T3261-2007
Dimensions (T*W*L) [mm]
Actual dimensions depend on
 the material used.
(0.3-0.5) x ≤600 x ≤1500
(0.6-0.8) x ≤800 x ≤1200
(0.9-6.0) x ≤1000 x ≤3000
(5.0-8.0) x ≤2500 x ≤4000
(8.0-60) x ≤2800 x ≤12000

Titanium Sheet / Titanium Foil
Manufactured according to ASTM B265. Custom cuttings on demand.

Materials Processing State Dimensions
 (thickness, width, length)
 [mm]
Standards
TA1, TA2 and others Cold rolled, annealed 0.4-0.8×30-300×1000
and longer
ASTM B265
 GB/T3622-1999
TA1, TA2 and others Cold rolled, annealed 0.01-0.3*30-300*500
and longer
ASTM B265
GB/T3622-1999

Titanium Punch plates for heat exchangers
· JISH4600TP 270C (TA1-A GB/T14845-93) , box-packed flat plates
· JISH4600TR 270C (TA1-A GB/T14845-93), sheet coil
· JISH4600TP 270C 0.2pd (TA9 GB/T14845-93) , box-packed flat plates
· JISH4600TP 270C 0.2pd (TA9 GB/T14845-93), sheet coil
Please inquire about other titanium plates and specifications.
