pure titanium plate

Titanium Plates, coil, Sheet, and Foil

We provide high quality titanium plates, titanium sheet, and titanium foil directly from China according to customer's requirements. Sheets and plates made of molybdenum and nickel are also available.

Hot rolling titanium plates/ coils are good material for further processing such as petroleum, chemical, electric power, medicine and environmental protection, and other various fields. Complete in specifications, variety of products, breadth, long Ti-coils, good strip shape, high precision of specification, stable in performance, punctual delivery, four forms: Ti-plates, Ti- coils, Ti-sheets, Ti-foils. We have many different kinds of delivery status such as hot rolling, annealing, shot blasting, acid picking.

Cold rolling titanium plates/ coils are widely used in petroleum, chemical, electric power, medicine and environmental protection, and other various fields. Complete in specifications, variety of products breath, good in shape, high precision of specification, surface cleanliness and consistency, homogeneous in organization.

Grades:

﹒ASTM GR.5, ASTM GR.7, ASTM GR.9, ASTM F136, TC4, TA8, TA9, Ti 15-3-3-3

﹒TA-0, TA1-A, TA1, TA2, ASTM GR.1, ASTM GR.2, ASTM ERT-1, ASTM ERT-2, ASTM F6

Materials	Manufacturing Process	Processing State	Standards
TA1, 2, 9, 10,  Gr1, 2, 3, 7, 11, 12, 17	Hot rolled  (3.0mm < thickness < 60mm)	Hot rolled,  annealed Shot blasting Acid picking	ASTM B265-95  GB/T3261-2007
TA1, 2, 9, 10,  Gr1, 2, 3, 7, 11, 12, 17	Cold rolled  (0.2mm < thickness < 4.0mm)	Cold rolled,  annealed smooth	ASTM B265-95  GB/T3261-2007
TC1, TC2, TC4 Gr5, Gr23	Hot rolled  (4.1mm < thickness < 60mm)	Hot rolled, annealed Shot blasting Acid picking	ASTM B265-95  GB/T3261-2007
TC1, TC2, TC4 Gr5, Gr23	Cold rolled  (0.2mm < thickness < 4.0mm)	Cold rolled,  annealed smooth	ASTM B265-95  GB/T3261-2007
Dimensions (T*W*L) [mm] Actual dimensions depend on  the material used.	(0.3-0.5) x ≤600 x ≤1500 (0.6-0.8) x ≤800 x ≤1200 (0.9-6.0) x ≤1000 x ≤3000 (5.0-8.0) x ≤2500 x ≤4000 (8.0-60) x ≤2800 x ≤12000



Materials	Processing State	Dimensions  (thickness, width, length) [mm]	Standards
TA1, TA2  and others	Cold rolled,  annealed	0.4-0.8×30-300×1000  and longer	ASTM B265  GB/T3622-1999
TA1, TA2  and others	Cold rolled,  annealed	0.01-0.3*30-300*500  and longer	ASTM B265  GB/T3622-1999

Titanium Punch plates for heat exchangers

· JISH4600TP 270C (TA1-A GB/T14845-93) , box-packed flat plates

· JISH4600TR 270C (TA1-A GB/T14845-93), sheet coil

· JISH4600TP 270C 0.2pd (TA9 GB/T14845-93) , box-packed flat plates

· JISH4600TP 270C 0.2pd (TA9 GB/T14845-93), sheet coil

Please inquire about other titanium plates and specifications.
