Turbo Billet Turbocharger Compressor Titanium Impeller, Titanium Vane Wheel, Titanium Impellor

We provide high precise machining titanium or nickel pipes, balls, elbows, reducers (small/big head), T-fittings, flange, valve, as well as other branch connections, casing caps, tube sockets,ti valve, ti elbow, ti fitting, ti flange, integral pipe flange, steel pipe flange, threaded flange, slip-on flange (SO); slip-on welding flange, socket welding flange, lap joint flange (LJF) , welding neck flange (WNF), blind flange, orifice flange, reducing flange, pad type flange, loose hubbed flange, welding plate flange, welding neck collar, welding-on collar, stub end, lap, lapped pipe end,loose plate flange,titanium or nickel ball, reducer,branch connections, casing cap, tube socket, Ti pump, equal tee from China.
Quantity:
  • ee-922

  • elegant

CNC Precision machined parts  specifications:CNC Lathe  Precision Metal Parts
CNC Metal parts, CNC Lathe parts, Machined parts, CNC parts, Precision Machining parts, OEM/ ODM, Anodize.
Anodizing, heat treatment, polishing, PVD/CVD coating, galvanized, electroplating, plating(nickle,silver,gold...), spraying, laser etching, sandblasting, painting and so on.
CNC Metal parts, CNC Lathe parts, Machined parts, CNC parts, Precision Machining parts, OEM/ ODM, Anodize, Oxide, Bead blasting, Various Electron Plating and surface treatments

CNC Lathe metal parts can be machined with tiny tolerance, precise dimensions and a smooth surface. Roughness is typically considered to be the high frequency, short wavelength component of a measured surface.

Packaging & Delivery
Packaging Details
- internal packaging: PP bag, bubble bag, plastic wrap, etc
- external packaging: carton box, wood box, pallet, etc
- or as per your requirement

Item name
CNC machining, milling, drilling
Tolerance
according to customer drawing






Material
Stainless Steel: SS201,SS301,SS303, SS304, SS316, SS416 etc.
Steel: mild steel, Carbon steel, 4140, 4340, Q235, Q345B, 20#, 45# etc.
Aluminum: AL6061, Al6063, AL6082, AL7075, AL5052, A380 etc.
Brass: HPb63, HPb62, HPb61, HPb59, H59, H68, H80, H90 etc.
Copper: C11000,C12000,C12000, C36000 etc.
Plastic: ABS, PC, PE, POM, Delrin, Nylon,PP, Peek etc.
Other: Titanium,Titanium alloy etc.We handle many other type of materials. Please contact us if your required material is not listed above.






Surface Treatment
Stainless Steel:Polishing, Passivating, Sandblasting, Laser engraving,Oxide black,Electrophoresis black
Steel: Zinc plating, Oxide black, Nickel plating, Chrome plating, Carburized, Powder Coated, Heat treatment.
Aluminum:Clear Anodized, Color Anodized, Sandblast Anodized, Chemical Film,Brushing,Polishing.
Brass: Nickel plating,chrome plating,Electrophoresis black,Oxide black,Powder coated.
Plastic:Plating gold (ABS), Painting, Brushing (Acylic), aser engraving.
Drawing Format
jpg/.pdf/.dxf/.dwg/.igs./.stp/x_t. etc
Testing Machine
CMM,Digital Height Gauge, caliper, Coordinate measuring machine, projecter machine, roughness tester, hardness tester and so on
MOQ
1 piece
Delivery time
10-15 days after placed order
Quality Control
Conducted by ISO9001 System and PPAP Quality control documents
Inspection
Solidworks,Pro/Engineer,Auto CAD,PDF,JPG
Quality Control
Quality Control
Inspection
IQC, IPQC,FQC,QA


We provide titanium or nickel pipes, elbows, reducers (small/big head), T-fittings, flange, valve, as well as other branch connections, casing caps, tube sockets from China.
· Elbows of 30°, 45 °,  60° , 90 °, 180 ° and any arbitrary bending from titanium, nickel and other alloys, Hastelloy alloys as well as other special metals.
· DN80-DN1200 welded pipes of titanium, nickel and other alloys, Hastelloy alloys as well as other special metals.
· We implement and refer to technical standards such as GB12459-2000, GB13401-1990, HG3651-1999, and ASTM B363.

Titanium Fittings

DN Outer diameter D (end) Dimensions
 (center to end)
Dimensions
 (center to center)
Dimensions
 (back to end)
45° Elbow H 90° Elbow F 180° Elbow P 180° Elbow K
A series B series Long radius Long radius Short radius Long radius Short radius Long radius Short radius
15 21.3 18 16 38 -- 76 -- 48 --
20 26.9 25 16 38 -- 76 -- 51 --
25 33.7 32 16 38 25 76 51 56 41
32 42.4 38 20 48 32 95 64 70 52
40 48.3 45 24 57 38 114 76 83 62
50 60.3 57 32 76 51 152 102 106 81
65 76 76 40 95 64 191 127 132 100
80 89 89 47 114 76 229 152 159 121
90 102 -- 55 133 89 267 178 184 140
100 114 108 63 152 102 305 203 210 159
125 140 133 79 190 127 381 254 262 197
150 168 159 95 229 152 457 305 313 237
200 219 219 126 305 203 610 406 414 313
250 273 273 158 381 254 762 508 518 391
300 324 325 189 457 305 914 610 619 467
350 356 377 221 533 356 1067 711 711 533
400 406 426 253 610 405 1219 813 813 610
450 457.0 480 284 686 457 1372 914 914 686
500 508 530 316 762 508 1524 1016 1016 762
550 560 - 347 838 560 - - - -
600 610 630 380 914 610 - - - -
650 660 - 410 990 660 - - - -
700 711 720 442 1067 711 - - - -
750 762 - 473 1143 762 - - - -
800 813 820 505 1219 813 - - - -
850 864 - 537 1295 864 - - - -
900 914 920 568 1372 914 - - - -
950 965 - 600 1448 965 - - - -
1000 1016 1020 631 1524 1016 - - - -
1050 1067 - 663 1600 1067 - - - -
1100 1120 1120 694 1676 1120 - - - -
1150 1168 - 726 1753 1168 - - - -
1200 1220 1220 758 1829 1220 - - - -

Titanium  Flange
Material Grade Gr1, Gr1, Gr2,Gr7, Gr9, Gr23, TI-6Al4v,
Certification    ISO9001:2008 BV
Standard ANSI B16.5,JIS B2220, DIN2627-2628,ASME,GB/T 9116, ASTM B16.5
size 1/2"~ 30"NB, NPS 1/2 - NPS 24 (DN 10 - 2000)
Pressure Class PN0.25~32Mpa
(DIN)   PN6,PN10,PN16,PN25 though PN250
150LB, 250LB ,300LB, 400 LB,500LB, 600 LB,
900LB, 1500LB,2500LB
Technique Forged and CNC Machined
type WNRF , SORF , BLIND ,SW, PL
Flange surface FF,RF,TG,RJ etc
Application products used in cars, glasses,medical equipment ,
electronics , petrochemical equipment
Advantage    1. Long service life
2. corrosion -resistant
3.high yeiled strength and tensile strength.
